☀️ Reliable Solar Pumping with Real-Time MPPT Control
The CG Emotron VSR48004 is a durable solar pump inverter that efficiently powers 2.2kW three-phase motors using solar energy. Engineered for remote and agricultural pumping needs, it converts variable DC solar power into stable AC output to run water pumps efficiently—ideal for borewells, irrigation systems, livestock watering, and village water supply.
Equipped with advanced MPPT tracking and intelligent automation, it ensures up to 99% energy efficiency under real-time sunlight variations.
⚙️ Technical Specifications:
🔧 Motor Power: 2.2 kW
☀️ Recommended Solar Array: 3.5–4 kWp
🔌 Max DC Input Current: 10 A
🔌 Output Current: 4 A
📐 Dimensions (mm): 186.6 x 116 x 175
⚖️ Weight: 3 kg
⚡ Input & MPPT Control:
🌞 DC Input Voltage Range: 230 VDC – 800 VDC
🌞 MPPT Operating Range: 450–600 VDC
📈 Recommended Voc: 600–700 VDC
🌟 MPPT Efficiency: 99%
🌟 Key Features:
✅ Real-Time MPPT Tracking – 99% conversion efficiency
✅ Smooth Pump Startup – Protects equipment and saves energy
✅ 200% Overload Support – Ideal for demanding motor startups
✅ AC/DC Dual Input – Flexibility for hybrid systems
✅ Auto Sleep & Wake – Light-sensitive operation for day-night control
✅ Durable Design – Built for heat, dust, and rural environments
✅ LCD Display – Oscilloscope-style visual feedback
✅ Multi-Level Protection – Dry run, stall, overload, and thermal safeguards
✅ RS485 Modbus Ready – Plug-and-play remote integration
🌍 Best Applications:
🌱 Solar-Powered Irrigation Systems
🚿 Remote Water Supply & Rural Wells
🐂 Cattle and Livestock Farms
🏞️ Village Water Projects
💧 Eco-Agriculture and Green Energy Systems
🛠️ Why Choose VSR48004?
CG Emotron’s VSR48004 solar VFD is crafted with in-house power components and industrial-grade reliability. Its compact size, low startup cost, and maximum energy conversion make it the smart choice for modern solar water pumping.
